ESD Common Grounding 4 Pin Point

Get a Price/Quote

ESD Common Grounding 4 Pin Point Specification

Product Type
ESD Common Grounding 4 Pin Point

Material
Conductive ABS Plastic

Application
Electrostatic Discharge Safety Grounding

Surface Resistance
10^6 - 10^9 Ohms

Usage
Grounding multiple ESD working points or wrist straps

Output Voltage
0V (passive ground point)

Testing Function
No built-in test function

Trigger Mode
Manual connection

Detection Method
Physical connection to ground

Size
Compact

Dimension (L*W*H)
120 mm x 35 mm x 28 mm

Weight
45 g

Color
Black/Yellow

Connection
Threaded Terminal for Earth Cable

Mounting Type
Screw Mount or Adhesive Back Mount

Number of Pins
4 Common Ground Banana Jack Sockets

Operating Temperature
-10C to +60C

Compatibility
Standard ESD Wrist Strap and Earth Bonding Plugs

Accessories Included
Mounting Screws and Instruction Manual

Resistance to Chemicals
High, Suitable for Industrial Environments

Conductor Type
Nickel Plated or Stainless Steel Brass

About ESD Common Grounding 4 Pin Point

The ESD Common Grounding 4 Pin Point is a reliable grounding solution designed to ensure effective electrostatic discharge (ESD) control in sensitive environments. Featuring a 4-pin configuration, this grounding point allows for multiple connections, providing a centralized grounding location for various equipment and workstations. Constructed from durable materials, it offers excellent conductivity and resistance to corrosion, ensuring long-lasting performance. Ideal for use in electronics manufacturing, cleanrooms, and laboratories, the 4-pin grounding point helps maintain compliance with ESD standards, protecting both personnel and sensitive components from electrostatic damage.

Reliable ESD Grounding Solution

Protect your personnel and sensitive electronics with the ESD Common Grounding 4 Pin Point. Designed for industrial and electronics assembly settings, it delivers secure and simultaneous grounding for up to four ESD wrist straps. Its robust materials and high chemical resistance make it ideal for demanding working environments.

Flexible Installation Options

Choose between screw mount or adhesive backing to install the unit on benches, trolleys, or workstations. The compact design and included mounting screws facilitate quick and lasting setup, accommodating a range of workspace requirements. An instruction manual guides you through the process for trouble-free installation.

Engineered for Compatibility and Safety

This grounding point is universally compatible with standard ESD wrist straps and earth bonding plugs. Nickel plated or stainless steel brass conductors ensure stable electrical connections, while the conductive ABS body offers a safe and durable enclosure. Maintain industry-standard ESD practices and protect against static discharge effectively.

FAQs of ESD Common Grounding 4 Pin Point:

Q: How do I install the ESD Common Grounding 4 Pin Point?

A: You can install the ESD Common Grounding 4 Pin Point using the included mounting screws for a permanent fixture or the adhesive back mount for a non-invasive setup. The instruction manual provides step-by-step guidance for both options.

Q: What types of wrist straps and earth bonding plugs are compatible with this grounding point?

A: This unit supports standard ESD wrist straps and earth bonding plugs, making it suitable for most industrial and electronics assembly environments where proper grounding is essential.

Q: When should I use the 4-pin common ground point instead of a single-point solution?

A: Use the 4-pin version when you need to ground multiple working points or wrist straps simultaneously, such as at shared workstations or multi-person assembly lines. It ensures efficient ESD safety across various users.

Q: Where can this grounding point be mounted in the workplace?

A: The compact design allows it to be mounted on workbenches, carts, walls, or any conductive surface where ESD protection is required. Its flexible mounting options suit a wide range of industrial environments.

Q: What are the benefits of the conductive ABS plastic material used in this product?

A: Conductive ABS plastic offers durability, high resistance to chemicals, and a safe surface resistance range (10^6 - 10^9 Ohms), making the device reliable for long-term industrial use.

Q: How is the earth connection made with this device?

A: A threaded terminal on the unit allows connection to an earth cable, establishing a reliable route for static electricity to dissipate safely to ground.

Q: Is there an integrated testing function for this grounding point?

A: No, this product does not include a built-in testing function. Physical connection to ground is achieved via manual attachment of cables and straps, with verification handled by standard ESD testing procedures.
